Connection diameter
400 mm
Number of phases
1~
Number of poles
4
Operation
On/Off, Potentiometer
Motor control type
36925
Category code
35
Capacitor capacitance
7 µF
Capacitor voltage
450 V
Weight
15.7 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP00
Motor insulation class
F
Max. operating current
1 A
Max. pressure
270 Pa
Max. air volume
3300 m³/h
Max. current consumption
1 A
Max. power consumption
211 W
Max. stat. yield
47.2%
Max. permissible medium temperature
60 °C
Max. permissible medium temperature at nominal current
60 °C
Max. permissible ambient temperature
60 °C
Max. permissible ambient temperature at rated current
60 °C
Max. speed
1440 1/min
Max. total yield
51%
With timer
No
Minimum allowable voltage
230 V
Min. operating temperature
-25 °C
Motor protection
TAI
Engine type
1~
Nom. frequency
50 Hz
Nominal speed
1410 1/min
Nominal power consumption
211 W
Nom. voltage
230 V
Nominal current
0.95 A
