Connection diameter
280 mm
Number of phases
1~
Number of poles
2
Operation
On/Off, Potentiometer
Motor control type
36925
Category code
35
Capacitor capacitance
0 µF
Capacitor voltage
0 V
Weight
7.65 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP00
Motor insulation class
F
Max. operating current
1.12 A
Max. pressure
510 Pa
Max. air volume
2170 m³/h
Max. current consumption
1.12 A
Max. power consumption
239 W
Max. stat. yield
49.7%
Max. permissible medium temperature
60 °C
Max. permissible medium temperature at nominal current
60 °C
Max. permissible ambient temperature
60 °C
Max. permissible ambient temperature at rated current
60 °C
Max. speed
2830 1/min
Max. total yield
52.9%
With timer
No
Min. operating temperature
-25 °C
Motor protection
TAI
Engine type
1~
Nom. frequency
50 Hz
Nominal speed
2750 1/min
Nominal power consumption
239 W
Nom. voltage
230 V
Nominal current
1.07 A
