RUCK Pipe fan plastic | Ø280mm | 267 W | 2440 m³/h | 630 Pa

Image 1 / 5

Energy-efficient inline fan with a plastic housing and EC motor. Capacity up to 2440 m³/h, max. pressure 630 Pa, and 267 W power. Continuously variable speed control and a mixed-flow impeller ensure quiet and efficient airflow in ventilation ducts.

Availability:
In stock
Brand: RUCK
Delivery time: 1- 3 Working Days
Delivery
Delivery time is only an indication. When available delivery will be within the listed working days.
Article code: HT65130701
Garantie: 1 year

€785,12 €497,71 (€602,23 Incl. BTW)

offer valid until: t/m 31-10-2025

Description

Connection diameter
280 mm
Number of phases
1~
Operation
On/Off, Potentiometer
Motor control type
0-10V
Category code
35
Capacitor capacitance
0 µF
Capacitor voltage
0 V
Weight
5.55 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP33
Motor insulation class
F
Max. operating current
1.86 A
Max. pressure
630 Pa
Max. air volume
2440 m³/h
Max. current consumption
1.86 A
Max. power consumption
267 W
Max. stat. yield
58.6%
Max. permissible medium temperature
45 °C
Max. permissible medium temperature at nominal current
45 °C
Max. permissible ambient temperature
45 °C
Max. permissible ambient temperature at rated current
45 °C
Max. speed
3170 1/min
Max. total yield
62.2%
With timer
No
Min. operating temperature
-30 °C
Motor protection
TEC
Engine type
EC
Nom. frequency
50 Hz
Nominal speed
2970 1/min
Nominal power consumption
267 W
Nom. voltage
230 V
Nominal current
1.77 A
