Connection diameter
315 mm
Number of phases
1~
Operation
On/Off, Potentiometer
Motor control type
0-10V
Category code
35
Capacitor capacitance
0 µF
Capacitor voltage
0 V
Weight
6.9 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP33
Motor insulation class
F
Max. operating current
1.96 A
Max. pressure
600 Pa
Max. air volume
2960 m³/h
Max. current consumption
1.96 A
Max. power consumption
282 W
Max. stat. yield
53.2%
Max. permissible medium temperature
45 °C
Max. permissible medium temperature at nominal current
45 °C
Max. permissible ambient temperature
45 °C
Max. permissible ambient temperature at rated current
45 °C
Max. speed
2800 1/min
Max. total yield
56.7%
With timer
No
Min. operating temperature
-30 °C
Motor protection
TEC
Engine type
EC
Nom. frequency
50 Hz
Nominal speed
2470 1/min
Nominal power consumption
282 W
Nom. voltage
230 V
Nominal current
1.87 A
