Connection diameter
355 mm
Number of phases
1~
Operation
On/Off, Potentiometer
Motor control type
0-10V
Category code
35
Weight
9.75 kg
IP protection gr. compl. app.
IP00
IP protection class terminal box
IP44
IP protection class motor
IP20
Motor insulation class
B
Max. operating current
3.37 A
Max. pressure
930 Pa
Max. air volume
4790 m³/h
Max. current consumption
3.37 A
Max. power consumption
731 W
Max. stat. yield
58.4%
Max. permissible medium temperature
60 °C
Max. permissible medium temperature at nominal current
60 °C
Max. permissible ambient temperature
60 °C
Max. permissible ambient temperature at rated current
60 °C
Max. speed
3010 1/min
Max. total yield
62%
With timer
No
Min. operating temperature
-25 °C
Motor protection
TEC
Engine type
EC
Nom. frequency
50 Hz
Nominal speed
2900 1/min
Nominal power consumption
731 W
Nom. voltage
230 V
Nominal current
3.21 A
