Connection diameter
250 mm
Number of phases
1~
Number of poles
2
Operation
On/Off, Potentiometer
Motor control type
36925
Category code
35
Capacitor capacitance
5 µF
Capacitor voltage
450 V
Weight
5.7 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP00
Motor insulation class
F
Max. operating current
0.81 A
Max. pressure
435 Pa
Max. air volume
1625 m³/h
Max. current consumption
0.81 A
Max. power consumption
170 W
Max. stat. yield
46.6%
Max. permissible medium temperature
50 °C
Max. permissible medium temperature at nominal current
50 °C
Max. permissible ambient temperature
50 °C
Max. permissible ambient temperature at rated current
50 °C
Max. speed
2880 1/min
Max. total yield
49.5%
With timer
No
Minimum allowable voltage
230 V
Min. operating temperature
-25 °C
Motor protection
TAI
Engine type
1~
Nom. frequency
50 Hz
Nominal speed
2820 1/min
Nominal power consumption
170 W
Nom. voltage
230 V
Nominal current
0.77 A
Reverse current
2.3 A
