Connection diameter
200 mm
Number of phases
1~
Operation
On/Off, Potentiometer
Motor control type
0-10V
Category code
35
Capacitor capacitance
0 µF
Capacitor voltage
0 V
Weight
3.2 kg
IP protection gr. compl. app.
IPX4
IP protection class terminal box
IP44
IP protection class motor
IP54
Motor insulation class
F
Max. operating current
1.01 A
Max. pressure
440 Pa
Max. air volume
1300 m³/h
Max. current consumption
1.01 A
Max. power consumption
121 W
Max. stat. yield
42.6%
Max. permissible medium temperature
45 °C
Max. permissible medium temperature at nominal current
45 °C
Max. permissible ambient temperature
45 °C
Max. permissible ambient temperature at rated current
45 °C
Max. speed
3170 1/min
Max. total yield
48%
With timer
No
Min. operating temperature
-30 °C
Motor protection
TEC
Engine type
EC
Nom. frequency
50 Hz
Nominal speed
2970 1/min
Nominal power consumption
121 W
Nom. voltage
230 V
Nominal current
0.96 A
