| EAN | 8717775930396 |
|---|
| Connection |
Bottom connection |
|---|---|
| Installation depth |
158 – 198 mm |
| Size |
200 x 200 mm |
| Anti-slip value grid |
R10 |
| Tax Schedule |
30 kN (3,000 kg) |
| Load class grating EN 1253 |
L15 (1,500 kg) |
| Capacity (max.) |
1.60 l/s |
| Connection diameter |
ø 75 mm |
| Diameter bucket |
ø 136 mm |
| Rotatable 360° |
Yes |
| Bucket |
Yes |
| Bucket height |
103 mm |
| Tiltable |
Yes |
| Material |
Plastic + stainless steel 316 edge/grid |
| Cuff material |
SBR rubber |
| Material attachment |
Stainless steel AISI 316 (EN 1.4401) |
| Material odor trap |
PPC plastic |
| Material grid |
Stainless steel AISI 316 (EN 1.4401) |
| Floor drain material |
ABS plastic |
| Material thickness grid |
14.0 mm |
| Surface treatment grid |
Brushed |
| Placement advice |
Yes |
| Product protection |
Mortar lid |
| Scent lock |
60 mm |
| Removable odour trap |
Yes |
| Slot width grid |
10.0 mm |
| Application |
Industry, Utility |
| Locked grid |
No |
| Glueable |
Yes |
| Adjustable vertically |
40 mm |
| Adjustability |
Adjustable in height |
| Floor drain standard |
EN 1253 |
| Shape grid |
Square, slotted holes |
| Dirt collection basket |
No |
| Water lock standard |
EN 1253 |
