Feet adjustable in height

Yes

Adjustable in height from

1890 mm

Height adjustable up to

1940 mm

Double-walled door

Yes

Suitable for under-construction

No

Tablet height max.

655 x 805 mm

Height with door open

2275 – 2325 mm

Connection value

8.18 kw

Tension

400 V

Frequency

50 Hz

Device connection

3 NAC

Boiler heating

6 kW

Tank heating

3 kW

Dry-running protection

Yes

Indicator light

Warm up
Ready to use
In business

On/Off switch

Yes

Drain pump

No

Water softener

No

Rinse aid dosing pump

Yes

Door contact switch

Yes

Safety thermostat

Yes

Detergent dosing pump

Yes

Basket dimensions

550 x 665 mm

Duration

120 / 240 / 360 / 480 / 600 seconds

Capacity/hour max.

30 baskets

Self-cleaning

Yes

Double-walled

Yes

Tank capacity

50 liter

Water consumption at 2 bar

4.2 litres / rinse cycle

Water pressure

2 – 4 bar

Water supply

G 3/4``

Water drainage

Ø 32 mm

Inclusive

1 universal basket
1 tray basket
1 cutlery holder
1 rinse grid

Properties

Electronic thermo-stop
Plus system (pressure booster pump, break tank, pressureless boiler)
Water supply temperature: 10 °C to 55 °C
2 rinse arms, each with 1 rinse pump
Double sieve (removable waste collector and pump sieve)
Deep drawn wash basin, with levels
Easy removal of the filters
Horizontal self-cleaning pump strainer
Self-diagnosis system
Stand-by function
Multi-colored START control button
Multilingual control menu

Number of washing programs

5

Material

Stainless steel

Width

730 mm

Depth

850 mm

Height

1890 mm

Weight

183.5 kg
