This professional stainless steel drain is suitable for the efficient and hygienic drainage of water in professional spaces. The drain is made of high-quality 14301 stainless steel and has a high mechanical load capacity. Thanks to its compact dimensions of 300 x 300 mm , the drain is suitable for various applications where a reliable floor drain is required.

The drain is equipped with a removable odor trap, dirt trap, and stainless steel grate . The odor trap has a water seal height of 70 mm and helps prevent unpleasant odors from the drainage system from entering the room. The dirt trap collects dirt and solid particles, making the drainage system easier to keep clean.

With a discharge capacity of 2.5 l/s at 20 mm backwater, this drain can handle large volumes of water. The manufacturer states a discharge capacity of at least 2.4 l/s. The horizontal outlet has a nominal diameter of DN100 and is suitable for connecting SML pipes.

The drain is suitable for thin floor coverings , such as epoxy resin. There is no adhesive edge around the perimeter. The included stainless steel grate has load class L15 according to EN 1253-1 , making the drain suitable for applications where a robust and durable design is desired.

Specifications

• Drain material: Stainless steel 14301
• Grate material: Stainless steel V2A
• Dimensions: 300 x 300 x 240 mm
• Length: 300 mm
• Width: 300 mm
• Height: 240 mm
• Nominal discharge diameter: DN100
• Outlet: Horizontal
• Discharge capacity: 2.5 l/s at 20 mm backwater
• Minimum discharge capacity: ≥ 2.4 l/s
• Water seal height: 70 mm
• Odor trap: Yes, removable
• Debris trap/sludge trap: Yes
• Schedule: Yes
• Load class: L15 according to EN 1253-1
• Suitable for thin floor coverings
• Suitable for SML pipes
• System: 185
• Number of drains: 1
• Net weight: 5 kg
• Gross weight: 5 kg
