Insulated copper pipe 1 1/8" – 4 meters length
This high-quality insulated copper pipe 1 1/8" is designed for professional applications in air conditioning, refrigeration, and climate control. The copper pipe has an outer diameter of 28.58 mm and is supplied in lengths of 4 meters per piece. With two pieces per box, this version is practical for various professional installation, maintenance, and assembly tasks.
The piping is manufactured from high-quality, flexible copper and has a constant wall thickness of 1.0 mm. The flexible copper makes the piping easy to work with during installation and helps to lay the piping route efficiently. This makes this copper piping a practical choice for installers working on professional cooling and air conditioning systems.
The copper pipe is fitted all around with 10 mm thick PE insulation. The insulation consists of two layers of resilient, high-quality PE sheath and has a closed cell structure on both the inside and outside. This construction ensures a high insulation value and helps limit condensation around the pipe.
The exterior of the insulation features a hard, white protective wall. This provides extra protection for the pipe during transport, storage, and installation. Despite the sturdy outer wall, the insulation remains easy to work with and can be bent with the pipe without creases easily forming.
The heat-resistant inner layer is suitable for temperatures up to 110 °C. The thermal conductivity is a maximum of 0.043 W/mK, providing the insulation with a high insulation value. This helps limit unwanted heat transfer and contributes to the efficient operation of air conditioning and refrigeration systems.
The copper cable complies with EN 13501-1 and has fire class BL-s1-d0. The white protective cap protects the end and makes the cable easily recognizable during storage and installation. The cable is supplied in a box of two, making this packaging suitable for various professional installation projects.
This 1 1/8" insulated copper pipe, 4 meters in length, is therefore a suitable solution for professional installers, technical services, and companies in the hospitality, air conditioning, and refrigeration industries. The combination of high-quality flexible copper, a constant wall thickness of 1.0 mm, and 10 mm PE insulation makes this pipe suitable for a wide range of professional applications.
Specifications:
- Type: insulated copper pipe
- Pipe size: 1 1/8"
- Length: 4 meters per piece
- Quantity: 2 pieces per box
- Outer diameter: 28.58 mm
- Wall thickness: 1.0 mm
- Insulation thickness: 10 mm
- Pipe material: high-quality, flexible copper
- Wall thickness: constant
- Insulation material: high-quality PE sheath
- Insulation structure: 2 layers
- Inner wall: closed cell structure
- Outer wall: closed cell structure
- Exterior finish: hard, white exterior wall
- Heat-resistant inner layer: up to 110 °C
- Thermal conductivity: maximum 0.043 W/mK
- Fire class: BL-s1-d0
- Standard: EN 13501-1
- Protective cap: white
- Packaging: 2 pieces per box
- Flexibility: flexible and easy to work with
- Insulation: bending without creases in the insulation
- Condensation: condensation-free
- Application: air conditioning, refrigeration technology and climate control systems
