Technical specifications

• Dimensions WxDxH: 226x490x580 mm
• Drain height: 118 mm
• Hourly capacity of chilled water: approx. 10 litres (approx. 80 glasses of 120 ml each).
• Dispensing speed: approx. 2.5 sec. per glass of 120 ml.
• Start-up time: approx. 9 min.
• Temperature adjustable: 2°C - 12°C
• Connection value: 1N~220-240V / 50Hz / 225W
• Water connection: 3/4 ”
• Min. water pressure: 0.02 MPa (0.2 bar)
• Max. water pressure: 1 MPa (10 bar)
• Refrigerant: R134a
• Weight: 24.3 kg
